FMP53
Update: 2019/5/31 View:
- Brand: E+H
- Type: FMP53
- Price: RMB
- Promotion: RMB
Introduction
Continuous / Liquids| Measuring Principle | Guided radar | |
| Characteristic / Application |
Premium device. Hygiene Rod probe, ASME BPE + USP Class VI compliant, Integrated data memory, Factory precalibrated, Reliable measuring: in case of moved surface + foam, for changing medias, for filling via spray head. |
|
| Supply / Communication |
2-wire (HART / PROFIBUS PA/ FOUNDATION Fieldbus) 4-wire (HART) |
|
| Accuracy |
Rod probe:+/- 3 mm (0.12 in) |
|
| Ambient temperature |
-40...+80 °C (-40...+176 °F) |
|
| Process temperature |
–20...+150 °C ( –4...+302 °F) |
|
| Process pressure absolute / max. overpressure limit |
Vacuum...16 bar (Vacuum...232 psi) |
|
| Main wetted parts |
Rod probe: 304, 304L, 316L, PEEK |
|
| Process connection |
Thread: M24 |
|
| Process connection hygienic |
Tri-Clamp DIN11851 DIN11864-1 NEUMO Varivent N SMS |
|
| Sensor length |
Rod probe: 6 m (20 ft) |
|
| Max. measurement distance |
Rod: 6 m (20 ft) Min DK>1.6 |
|
| Output |
4...20 mA HART PROFIBUS PA FOUNDATION Fieldbus |
|
| Certificates / Approvals |
ATEX, FM, CSA, CSA C/US, IECEx, NEPSI Overfill prevention WHG SIL EN10204-3.1 3A, EHEDG CoC ASME-BPE |
|
| Options |
Sensor remote with 3 m/9 ft or 6 m/18 ft cable Weld-in adpater |
|
